1-045 Compression Latch Pr 14.1

for cutout 14.1 5
Nm
Compression latch with 4.5mm clamping Material:
grip. • Housing and insert shaft: zinc die,
• The closing process is always black
clockwise. • T-Handle: PA, black
• By turning the insert 90° the cam is at • Cam: zinc die, black
first put into closed position. • Adjusting screw and nut: steel, zinc
• By turning a further 90°, the cam will plated
be pulled towards the frame.
• The H-dimension can be easily
adjusted by the adjusting screw.
• Water- and dust-tight according to
IP65 DIN EN 60529.
• A pre-assembled quarter-turn can be
fitted through the cutout.

a) Compression latch (as drawn) complete with flat seal, nut and knob 220-9313
a1) slotted insert 4mm deep 220-9317
a2)socket hexagon (Allen) insert 4mm (5/32") 220-9318
